10GBASE-T Ethernet Media Converter SFP+ Port
sfiberoptic Cooper to fiber 10 Gigabit Media Converter is one port 10G pluggable SFP+ and RJ45 port, supporting any compatible 10G SFP+ modules including support for following standards: 10GBase-SR, 10GBase-LR,10GBase-ER,10GBase-LRM, and 10GBase-ZR.
Features
Support Jumbo Frame
Transparent Transport and very low delay
Support ITUT prescribed DWDM/CWDM wavelength
Support DMI function for SFP+ fiber module
Support Loopback test function
Economic In-band Management function
powerful Network Management function(Web，SNMP，Console etc.)
Support hot plugging
Support 2U Rack (16 channel) and standalone use
Full State Led display
Easy installation
UTP cable length detection(only RJ45 interface)
Applications
Connection between fiber to copper 10Gbps Ethernet equipment function as fiber-to-copper media converter for long distance transmission
Media converter for network backbone(SAN, LAN, MAN)
Can be applied in Telecommunication room, R&D laboratory, Data center, and etc.Specifications
Performance Data: Technical Indexes Transmission Speed: 10Gb/s Protocols: IEEE802.3an(10Gbase-T),IEEE802.3ae(10Gbase-SR/LR/ER/ZR) Access Type: 10G LAN Interface Type: Type: RJ45 To/From SFP+ Transmission Distance: SFP+ module: Up to 80Km 10Gbase-T: 100meters Cat .6a cable Maximum Packet Forwarding Rate: 14,880,950/S Network management information: Card type information SFP+ fiber module detection SFP+ fiber module DMI function (Temperature, Voltage, Optical power) Link status detector Enable/Disabled Loopback test function UTP cable length detection (only RJ45 interface) Remote card’s status monitor (only in pairs) Power requirement: Standalone: AC 220V OR DC -48V Rack-mountable : AC 85 - 220V OR DC -48V Power consumption: ≤9W Work Environment: Operating Temp: 0- 50 ℃ Storage Temp: -10- 70 ℃ Humidity: 5%-90% (non-condensing) Dimension: Card: 11.5mm (W) x 78mm (D) Standalone: 156mm (W) x 128mm (D) x 32mm (H)
