16 ports Industrial Ethernet Switch Unmanaged Rackmount Ethernet Switches

Product description

Industrial-grade non network switches based on 100M series is our company independent research and development of software of an industrial Ethernet switch, it has 16 * 10/100 base – TX (RJ45 electricity) adaptive Ethernet electricity of the mouth. Equipment with industrial design, high stability, high cost performance, the characteristics of high lightning protection level of radiation protection, at the same time have a DIN rail setup and desktop optional installation, can be widely used in telecommunications, electric power, water conservancy, finance, transportation, energy, public security, prison, military and other different areas, different industries to Ethernet business investment need any harsh conditions of the environment and occasion.
It adopts thickening aluminum alloy enclosure, beautiful and sturdy, and achieve IP40 protection grade: can be used independently, can also be installed to the professional use of 19 inch 4 u machine box is convenient for centralized management, and provide the standard temperature (0 ℃ - 70 ℃) and wide temperature – 40 ℃ - 85 ℃) model is optional.
The series of network type industrial Ethernet switches to satisfy the 3 c, CE/FCC, EN61000 each index in the standard, MTBF > 100000 hours, high stability, high reliability and performance is an ideal product used in the industrial environment.
Features

□16*10/100 – base – TX power
□full duplex/half duplex adaptive, MDI/MDIX automatic polarity reversal
□Strong electromagnetic interference resistance
□MINI type solid aluminum shell, is suitable for high temperature, high humidity, cold in the harsh environment application
□double port power supply, power supply voltage 12 - 56 v DC
□support twisted-pair mouth cross connection switch selection, system debugging installation is convenient
□Since the recovery fuse
□Aluminum frame, IP40 protection grade, 6 kv lightning protection
□Barrier-free > work an average of 100000 hours
□installation: desktop type, wall hung, guide rail type (optional)
Ethernet
electric: interface number: 16 interface type: RJ45, 10/100M
: (IEEE standard 802.23 10 baset, IEEE 802 base tx and 100 base – FX, IEEE802.3 z base – 1000 SX/LX)
Port to protect
electrostatic discharge: EN61000-4-2, lightning protection against surge: EN61000-4-5
the conduction and radiation: EN55022 rf transmission of electromagnetic field induction: EN61000-4-6
electrical instantly bursts: EN61000-4-4
Mechanical properties
enclosure: IP40 protection grade, metal shell
size: 60 * 111 * 111 mm
weight: 1 kg
installation: desktop type, wall hung, guide rail type installation (optional)
The industry standard
EMI: the FCC Part 15. CISPR (EN55022) class A
EMS:
EN61000-4-2 (ESD), EN61000-4-3 (RS);
EN61000-4-4 (EFT), EN61000-4-5 (Surge);
EN61000-4-6 (CS), EN61000-4-6 (common-mode transmission).
industry: IEC6100-6-2
Railway: EN50155.EN50121-4
Traffic: TS-2 NEMA
Coal: GB/T3836.1/2/3/4
machine: IEC68-2-6/27/32
work environment
Working temperature: -10-60 (normal grade); -40-85 (wide temperature range)
storage temperature: -40-85 C
Relative humidity >: 5-95% (no condensation)
Power Supply
input voltage: 48 VDC (12-56VDC)
Over current protection
connection: 2 sets of terminal blocks
Reverse protection: provide
