Fiber Optic Desktop Microscope 400G

Fiber Optic Desktop Microscope 400G

Fiber Optic Desktop Microscope 400T is the table model, the fiber microscope used in inspecting the fiber optic connector end surface quality, this fiber microscope has high definition of inspection, fiber microscope is convenient and fast operation, precise and highly effective, the image is clear and bright, saves the time, reduces the cost. And this fiber microscope has strong function of applications, is your end of the optical fiber connectors detection of measuring tool. Ideal through the monitor display optical fiber connectors end of the image, and other fiber microscope, compared with common observation, can be in uniform inspection standard, which is beneficial to the related training and Technical personnel.

1. 400G microscope is used with 10″ monitor.2. It is used to detect the defects of fiber optical connector end surface after polished or during the fiber usage, especially proper for detecting of MTRJ, MPO, and FC both in PC or APC connectors.
3. It can check SM, MM fiber optical connectors, PM fiber optical connectors.
4. Connectors proper for checking: FC/PC, FC/APC, SC/PC, SC/APC, ST/APC, LC/PC, LC/APC, MU, MTRJ etc.
5. Monitor is high definition of image. Showing enlarged 400 times, 200 times or 80 times.
6. The store has a camera function, data retention easier.

Electricity: DC12V

Times enlarged：400 times

Light source: Blue light

Monitor size: 10’’

Total weight: 4Kg

Operating: Manual
