10m Cisco SFP-10G-AOC10M Compatible 10G SFP+ Active Optical Cable

10m Cisco SFP-10G-AOC10M Compatible 10G SFP+ Active Optical Cable

QSFP/QSFP+ Passive Electrical Loopback is used for testing QSFP/QSFP+ transceiver ports in board level test. The electrical loopback provides a cost effective low loss method for QSFP/QSFP+ port testing. The is packaged in a standard MSA housing compatible with all QSFP/QSFP+ ports. Transmit data from the host is electrically routed, (internal to the loopback module), to the receive data outputs and back to the host. It provides an economical way to exercise QSFP/QSFP+ ports during R&D validation, production testing, and field testing. The provides QSFP/QSFP+ power Class 1, 2, 3 (standard), or 4 loading using a customer supplied +3.3V voltage supply.



Features



Customizable power consumption

Dual LED indicator

Custom Memory Maps

Built in diagnostic functions

Supports 40Gbps total data rate

Host-pluggable MSA footprint

Full SFF-8436 MSA Compliant

Temperature range from 0 to 80 C

No reference clock required

Compliant with SONET, SDH, GBE, FC

MSA Compliant EEPROMFeatures



¨ Electrical interface compliant to SFF-8431

¨ Hot Pluggable

¨ 850nm VCSEL transmitter, PIN photo-detector receiver

¨ Up to 300m on OM3 MMF

¨ Operating case temperature: 0 to 70℃

¨ All-metal housing for superior EMI performance

¨ RoHS compliant (lead free)



Applications



¨ 10 Gigabit Ethernet

¨ 4G and 8G Fibre Channel Applications

¨ 1x InfiniBand QDR. DDR, SDR

¨ High-performance computing clusters

¨ Servers, switches, storage and host card adapters

Description



sfiberoptic SFP+ Active Optical Cables are direct-attach fiber assemblies with SFP+ connectors. They are suitable for very short distances and offer a cost-effective way to connect within racks and across adjacent racks. sfiberoptic SFP+ Active Optical Cables’s length is up to 300 meters on OM3 MMF.



SFP+ AOC Specifications

Economical QSFP/QSFP+ Port Testing

Custom Memory Maps

Board Level System Testing

Excellent Signal Integrity

Application



QSFP Port/System Testing

ITU-T Recommendation G.957 (STM-1, 4 & 16)

Ethernet IEEE 802.3 (Gigabit, 10 Gigabit and 40 Gigabit Ethernet) SDR, DDR and QDR

SONET, SDH, GBE, FC Support, Infiniband

Optical characteristics

The following optical characteristics are defined over the Recommended Operating Environment unless otherwise specified.

Parameter	Symbol	Min.	Typical	Max	Unit	Notes
Transmitter
Center Wavelength	λt	840	850	860	nm
RMS spectral width	Pm	–	–	Note 1	nm
Average Optical Power	Pavg	-6.5	–	-1	dBm	2
Extinction Ratio	ER	3.5	–	–	dB	3
Transmitter Dispersion Penalty	TDP	–	–	3.9	dB
Relative Intensity Noise	Rin	–	–	-128	dB/Hz	12dB reflection
Optical Return Loss Tolerance		–	–	12	dB
Receiver
Center Wavelength	λr	840	850	860	nm
